Title Page
GE Multilin
215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: (905) 294-6222 Fax: (905) 201-2098
Internet:
http://www.GEindustrial.com/multilin
L90 Line Differential Relay
UR Series Instruction Manual
L90 Revision: 4.4x
Manual P/N: 1601-0081-J1 (GEK-112994)
Copyright © 2004 GE Multilin
GE Industrial Systems
831776A1.CDR
ISO9001:2000
GE Multilin's Quality Management
System is registered to
ISO9001:2000
QMI # 005094
UL # A3775
