GE P4A Technical Manual page 591

P54A/B/C/E
MENU TEXT
If Rst CB mon LO by is set to CB close then CB mon LO RstDly timer allows reset of CB lockout state after set time delay
Autoreclose Mode
Command to changes state of Auto-Reclose, In Service or Out of Service
AR Status
Status of the Auto Reclose - In Service / Out of service
CB Status Input
Setting to define the type of circuit breaker contacts that will be used for the circuit breaker control logic. Form A contacts match the status
of the circuit breaker primary contacts, form B are opposite to the breaker status.
When 1 pole is selected, individual contacts must be assigned in the Programmable Scheme Logic for phase A, phase B, and phase C. Setting
3 pole means that only a single contact is used, common to all 3 poles.
CB Status Time
Under healthy conditions the circuit breaker auxiliary contacts will be in opposite states. Should both sets of contacts be open or closed, it
indicates that either the contacts, or the wiring, or the circuit breaker are defective and an alarm will be issued after CB Status Time delay.
The time delay is set to avoid unwanted operation during normal switching duties.
Reset AROK Ind
If Res AROK by UI is set to Enabled, this command provides a pulse to reset the successful AR indication for both CB's
Reset CB LO
If Res LO by UI is set to Enabled, this command provides a pulse to reset the lockout for CB.
Note: This requires the condition that caused the lockout to have been cleared.
CB Total Shots
Indicates the total number of CB reclosures
CB SUCC SPAR
Indicates the total number of CB successful 1 pole reclosures
CB SUCC3PARShot1
Indicates the total number of CB successful 3 pole reclosures at 1st shot
CB SUCC3PARShot2
Indicates the total number of CB successful 3 pole reclosures at 2nd shot
CB SUCC3PARShot3
Indicates the total number of CB successful 3 pole reclosures at 3rd shot
CB SUCC3PARShot4
Indicates the total number of CB successful 3 pole reclosures at 4th shot
CB Failed Shots
Indicates the total number of CB failed reclose cycles
Reset CB Shots
P54xMED-TM-EN-1
COL ROW DEFAULT SETTING
07 0B No Operation
07 0E
07 11 52B 1 pole
07 7F 5
07 82 No
07 83 No
07 85
07 86
07 87
07 88
07 89
07 8A
07 8B
07 8C No
DESCRIPTION
No Operation
In Service
Out of Service
[Indexed String]
Out of Service
In Service
[Indexed String]
None
52A 3 pole
52B 3 pole
52A & 52B 3 pole
52A 1 pole
52B 1 pole
52A & 52B 1 pole
[Indexed String]
From 0.1 to 5 in steps of 0.01
[Courier Number (time-seconds)]
No
Yes
[Indexed String]
No
Yes
[Indexed String]
CB Total Shots
[Unsigned Integer (16 bits)]
CB SUCC SPAR
[Unsigned Integer (16 bits)]
CB SUCC3PARShot1
[Unsigned Integer (16 bits)]
CB SUCC3PARShot2
[Unsigned Integer (16 bits)]
CB SUCC3PARShot3
[Unsigned Integer (16 bits)]
CB SUCC3PARShot4
[Unsigned Integer (16 bits)]
CB Failed Shots
[Unsigned Integer (16 bits)]
No
Yes
[Indexed String]
Appendix B - Settings and Signals
AVAILABLE OPTIONS
B25
