Appendix B - Settings and Signals
MENU TEXT
Dir Aided AR
Setting that determines impact of aided Directional Comparison protection (DEF) on AR operation.
(Only in models with distance option)
TOR AR
Setting that determines impact of Trip On Reclose (TOR) on AR operation.
(Only in models with distance option)
I>1 AR
Setting that determines impact of first stage overcurrent protection on AR operation. Set Initiate AR if the trip should initiate a cycle, and
Block AR if trip should cause lockout. Set No action if trip should exert no specific logic control on the recloser.
(Only in models with distance option)
I>2 AR
Setting that determines impact of the second stage overcurrent protection on AR operation.
I>3 AR
Setting that determines impact of the third stage overcurrent protection on AR operation.
I>4 AR
Setting that determines impact of the fourth stage overcurrent protection on AR operation.
IN>1 AR
Setting that determines impact of the first stage earth fault overcurrent protection on AR operation.
IN>2 AR
Setting that determines impact of the second stage earth fault overcurrent protection on AR operation.
IN>3 AR
Setting that determines impact of the third stage earth fault overcurrent protection on AR operation.
IN>4 AR
Setting that determines impact of the fourth stage earth fault overcurrent protection on AR operation.
ISEF>1 AR
Setting that determines impact of the first stage sensitive earth fault overcurrent protection on AR operation.
ISEF>2 AR
B200
COL ROW DEFAULT SETTING
49 7A Block AR
49 7B Block AR
49 7C No Action
49 7D No Action
49 7E No Action
49 7F No Action
49 80 No Action
49 81 No Action
49 82 No Action
49 83 No Action
49 84 No Action
49 85 No Action
DESCRIPTION
Initiate AR
Block AR
[Indexed String]
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
No Action
Initiate AR
Block AR
[Indexed String]
P54A/B/C/E
AVAILABLE OPTIONS
P54xMED-TM-EN-1
