Fisher FIELDVUE DVC6200f Instruction Manual page 87

Instruction Manual
D103412X012
Table 4‐11. Output Block PV Status
FEATURE_SEL Transducer Mode,
PW Alarms Set PV Status
OOS
Man
Auto
Enabled
Auto
Auto
Auto
OOS
Man
Auto
Not Enabled
Auto
Auto
Auto
NOTES:
=
X No Effect
1. PV limit substatus reflects only READBACK limit substatus. SP limit substatus reflects only out block rate limits.
2. Firmware Revision 1.1 and earlier will set AO/DO PV Status to Bad if Feedback Sensor has failed, i.e.; Travel Sensor Fail. However, if the Travel Sensor fails, and the instrument falls back to
pressure, PV Status will remain good.
MAI Channel Map
TB > Configure/Setup > Detailed Setup > MAI Channel Map
Field Communicator
Allows the user to specify which transducer block parameter is available through each of the MAI Block channels
(MAI_CHANNEL_1 through MAI_CHANNEL_8 [95.1 through 95.8]). Transducer block parameters available to each
channel:
11 = FINAL_VALUE
12 = TRAVEL_TARGET
13 = FINAL_POSITION_VALUE
14 = TRAVEL
15 = SUPPLY_PRESS
16 = ACT_PRESS_A
17 = ACT_PRESS_B
Table 4‐12. Limit Sub Status
Out Block Transducer Mode
AO, DO OOS
AO, DO MAN
AO AUTO
AO AUTO
AO AUTO
AO AUTO
AO AUTO
DO AUTO
DO AUTO
DO AUTO
=
NOTE: X No Effect
Active PlantWeb
Actual Alarms
X
X
Fail
Maintenance, no Fail
Advisory, no Fail, no
Maintenance
None
X
X
Fail
Maintenance, no Fail
Advisory, no Fail, no
Maintenance
None
In Cutoff Region
X
X
High
Low
X
X
None
X
X
X
AO / DO
(2)
PV Status PV Substatus
Bad Device Failure
Bad Non‐specific
Uncertain Subnormal
Uncertain Non‐specific
Good Advisory
Good
Non‐Specific
Bad Device Failure
Bad Non‐Specific
Good Non‐Specific
Good Non‐Specific
Good Non‐Specific
Good Non‐Specific
18 = ACT_PRESS_DIFF
19 = DRIVE_SIGNAL
10 = TRAVEL_DEVIATION
11 = TEMPERATURE
12 = CYCLE_COUNT
13 = TRAVEL_ACCUM
Rate Limited Limit Sub‐Status
X Constant
X Constant
X High Limited
X Low Limited
High High Limited
Low Low Limited
None Not Limited
High High Limited
Low Low Limited
None Not Limited
Detailed Setup—Transducer Block
AO / DO
AO/DO PV
Limit Substatus
Constant
Constant
See table 4‐12
See table 4‐12
See table 4‐12
See table 4‐12
Constant
Constant
See table 4‐12
See table 4‐12
See table 4‐12
See table 4‐12
July 2013
(1)
85
