Creating an IPMP Group Using Link-State Only Failure Detection
1.
Create one or more "underlying" IP interfaces that will be used as components
of the IPMP group. Each interface must have an IP address to be used as the
probe source (see separate task to create a single-port interfaces above).
2.
Click the Interface
3.
Optionally change the name of the interface.
Click the IP MultiPathing Group check box.
4.
5.
Click the Use IPv4 Protocol or/and the Use IPv6 Protocol and specify the IP
addresses for the IPMP interface.
6.
Choose the interfaces created in the fist step from the Interfaces list.
7.
Set each chosen interface to be either "Active" or "Standby", as desired.
8.
Click "APPLY".
Creating an IPMP Group Using Link-State Only Failure
Detection
1.
Create one or more "underlying" IP interfaces with the IP address 0.0.0.0/8 to be
used as the components of the IPMP group (see separate task to create a single-
port interfaces above).
2.
Click the Interface
Optionally change the name of the interface.
3.
4.
Click the IP MultiPathing Group check box.
5.
Click the Use IPv4 Protocol or/and the Use IPv6 Protocol and specify the IP
addresses for the IPMP interface.
6.
Choose the interfaces created in the first step from the Interfaces list.
Set each chosen interface to be either "Active" or "Standby", as desired.
7.
Click "APPLY".
8.
64
Oracle ZFS Storage Appliance Administration Guide, Release OS8.6.x • September 2016
