Network Icons

* Disabled icons are shown at left.
The following icons are used to distinguish different types of objects and provide information of
secondary importance.
TABLE 4
Icon
Network Icons
These icons indicate the state of network devices and type of network datalinks:
TABLE 5
Icon

Dashboard Icons

The following icons indicate the current state of monitored statistics with respect to user-
configurable thresholds set from within Settings.
30 Oracle ZFS Storage Appliance Administration Guide, Release OS8.6.x • September 2016
Miscellaneous Icons
Description
allow
deny
storage pool
Network Icons
Description
active network device
inactive network device
network datalink
network datalink VLAN
network datalink
aggregation
network datalink
aggregation VLAN
Icon Description
SAS
SAS port
Icon Description
active Infiniband port
inactive Infiniband port
network datalink (IB
partition)
