Oracle ZFS Storage Appliance Administration Manual page 324

Configuring SNMP to Send Traps (BUI)
Property
Community name
Authorized network/subnet
Appliance contact
Username/password
Authentication
Privacy
Engine ID
Trap destinations
The SNMP service also provides the MIB-II location string. This property is sourced from the
System Identity
SNMP MIBs
If the SNMP services is online, authorized networks will have access to the following MIBs
(Management Information Bases):
TABLE 92
MIB
.1.3.6.1.2.1.1
.1.3.6.1.2.1.2
.1.3.6.1.2.1.4
.1.3.6.1.4.1.42
.1.3.6.1.4.1.42.2.195
.1.3.6.1.4.1.42.2.225
Note -
324 Oracle ZFS Storage Appliance Administration Guide, Release OS8.6.x • September 2016
Description
Toggles between public and user-input. If you select user-input, you must also enter a
community name. If you select v3, this property is not available.
Enter an appropriate IPv4 address and subnet (integers from 0-32). If you select v3, this
property is not available.
Enter an appropriate appliance contact.
Enter a valid username (max 501 characters) and password (8-501 characters). If you
select v1/2c, this property is not available.
Toggles between MD5 and SHA authentication algorithms. If you select v1/2c, this
property is not available.
Toggles between None and DES encryption algorithm. If you select v1/2c, this
property is not available.
The EngineID value hashed by snmpd. If SNMP was not previously enabled, the label
shows "0x000".
Lets you add IPv4 addresses. Use the "+" and "-" buttons to add or remove addresses.
configuration.
SNMP MIBs
Sun MIB files are available at https://your IP address or host name:215/docs/snmp/.
Purpose
MIB-II system - generic system information, including
hostname, contact and location
MIB-II interfaces - network interface statistics
MIB-II IP - Internet Protocol information, including IP
addresses and route table
Sun Enterprise MIB (SUN-MIB.mib.txt)
Sun FM - fault management statistics (MIB file linked
below)
Sun AK - appliance information and statistics (MIB file
linked below)
