Creating a Single Port Interface (BUI)
1.
Mouse over a device and click the drag-and-drop icon (
2.
Drag it to the Datalink list and release.
3.
Optionally set name and jumbo MTU.
Click "APPLY".
4.
5.
Now Drag the datalink over to the Interfaces list.
Set desired properties, and click "APPLY".
6.
7.
Click "APPLY" at the top of the screen to commit the configuration.
Creating an LACP Aggregated Link Interface (BUI)
1.
Click the Datalinks
Optionally set the datalink name.
2.
3.
Select LACP Aggregation.
4.
Select two or more devices from the Devices list, and click "APPLY".
5.
Click the Interfaces
6.
Set desired properties, choose the aggregated link from the Datalinks list, and
click "APPLY".
7.
Click "APPLY" at the top to commit the configuration.
Creating an IPMP Group Using Probe-Based and Link-State
Failure Detection
Do not use probe-based failure detection when there no systems (other than the cluster peer) on
the same subnet as the IPMP test addresses that are configured to answer ICMP echo requests.
icon.
icon.
Creating a Single Port Interface (BUI)
).
Configuring the Appliance
63
