Identifying the Server Ports

This section describes the pinouts of the server connectors.
Description
Learn about the Gigabit Ethernet ports.
Learn about the network management port.
Learn about the serial management port.
Learn about the video connector.
Learn about USB ports.

Gigabit Ethernet Ports

The server has four auto-negotiating 100/1000/10,000BASE-T gigabit Ethernet (GbE) system
domain ports. All four Ethernet ports use a standard RJ-45 connector. The transfer rates are
shown in the following table.
TABLE 16
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
The following figure and table describe the 10-GbE port pin signals.
Note -
Ethernet Port Transfer Rates
IEEE Terminology
100BASE-TX
1000BASE-T
10GBASE-T
Ethernet ports NET 2 and NET 3 are nonfunctional in single-processor systems.
Links
"Gigabit Ethernet Ports" on page 195
"Network Management Port" on page 196
"Serial Management Port" on page 197
"Video Connector" on page 198
"USB Ports" on page 199
Transfer Rate
100 Mbps
1,000 Mbps
10,000 Mbps
Identifying the Server Ports 195
