Oracle X6-2 Service Manual page 239

Setup Options Options
Current IPv4 Subnet Mask NA
in BMC (R/O)
Current IPv4 Default NA
Gateway in BMC
Refresh
IPv4 IP Assignment Static/Dynamic
IPv4 Address NA
IPv4 Subnet Mask NA
IPv4 Default Gateway NA
Commit
IPv6 Configuration
Channel Number (R/O)
Current IPv6 State (R/O) Enabled/Disabled
BIOS Advanced Menu Selections
Defaults Description
Example: 172.31.255.255
NA If the IPv4 Assignment is
set to Static, set the IPv4
subnet mask.
Example: 255.255.255.0
NA If the IPv4 Assignment is
set to Static, set the IPv4
default gateway
Example: 172.31.255.255
Refresh the current BMC
LAN information.
Static Current IPv4 assignment.
NA If set, current IPv4 address
is displayed.
NA If set, current IPv4 Subnet
Mask is displayed.
NA If set, current Default IPv4
Gateway is displayed.
Commit the current BMC
LAN information.
Current configuration
of the IPv6 settings is
displayed.
IPv6 addresses are written
with hexadecimal digits
and colon separators. For
example: 2001:0db0:000:
82a1:0000:0000:1234:
abcd.
IPv6 addresses are
composed of two parts: a
64-bit subnet prefix and
a 64-bit host interface
ID. To shorten the IPv6
address, you can (1) omit
all leading zeros, and (2)
replace one consecutive
group of zeros with a
double colon (::). For
example: 2001:db0:0:
82a1::1234:abcd.
1 Current channel number is
displayed.
Enabled Current IPv6 state is
displayed.
BIOS Setup Utility Menu Options 239
