Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
/SYS/MB/RISER3/PCIE4/PRSNT
/SYS/MB/RISER1/PCIE1/PCIESW
/SYS/MB/RISER1/PCIE1/PCIESW/
PRSNT
/SYS/MB/T_OUT_SLOT[1-3]
/SYS/MB/T_IN_SLOT[1-3]
/SYS/MB/T_CORE_NET01
/SYS/MB/T_CORE_NET23
/SYS/MB/T_IN_SLOT[1-3]
/SYS/MB/T_OUT_SLOT[1-3]
/SYS/MB/T_IN_PS
/SYS/SP
/SYS/SP/OK
260
Oracle Server X6-2 Service Manual • June 2016
IPMI Type
Description
Discrete
Internal HBA card inserted into slot 4
sensor
of PCIe riser 3
FRU
Optional Oracle PCIe NVMe switch
card, dedicated slot
FRU
Optional Oracle PCIe NVMe switch
card inserted into slot 1 of PCIe riser
1, dedicated slot
Threshold
Cooling zone chassis exhaust
sensor
temperature, located behind the
specified PCIe slots.
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Threshold
Cooling zone chassis inlet
sensor
temperature, located in front of the
specified PCIe slots.
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Threshold
Gigabit Ethernet controller die
sensor
temperature
Threshold
Gigabit Ethernet controller die
sensor
temperature
Threshold
PCIE slot input temperature
sensor
Threshold
PCIE slot output temperature
sensor
Threshold
Power supply unit (PSU) inlet
sensor
temperature, located directly in front
of the PSU 0 air inlet.
FRU
Service processor FRU
Indicator
SP OK LED
Values (if
applicable)
02h-
ENTITY_PRESENT
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
Degrees Celsius
Degrees Celsius
CPU 0, NET 0+1
Degrees Celsius
CPU 1, NET 2+3
Degrees Celsius
Degrees Celsius
Degrees Celsius
Degrees Celsius
Color: Green
Location: Front
panel
On: SP is operating.
