After you physically remove an NVMe storage drive from the server, wait at least 10
Note -
seconds before installing a replacement drive.
1. Remove the replacement drive from its packaging and place the drive on an
antistatic mat.
2. If necessary, remove the drive filler panel.
3. Align the replacement drive with the drive slot.
The drive is physically addressed according to the slot in which it is installed. It is important to
install a replacement drive in the same slot as the drive that was removed.
Slide the drive into the slot until the drive is fully seated.
4.
See frame [1] in Figure
5. Close the drive latch to lock the drive in place.
See frame [2] in Figure
Power On an NVMe Storage Drive and Attach a Device Driver
Type: #
1.
hotplug enable pcie13
2. Type: #
hotplug list –lc
The following status is displayed for the NVMe storage drive.
# hotplug list –lc
Connection State
Path
------------------------------------------------------------------
pcie13 Enabled PCIe-Native /pci@7a,0/pci8086,2f08@3/pci111d,80b5@4
To check the NVMe drive health, firmware level, temperature, get error log,
3.
SMART data, security erase, low level format, etc., type:
#
nvmeadm list
Related Information
"Storage Drive Status Indicators" on page 65
■
"Storage Drives Hot-Plug Conditions" on page 64
■
"Storage Drive Failure and RAID" on page 64
■
"Storage Drive Locations and Numbering" on page 64
■
Power On an NVMe Storage Drive and Attach a Device Driver
10.
10.
Description
Servicing CRUs That Do Not Require Server Power-Off 71
