Remove The Front Indicator Module - Oracle X6-2 Service Manual

Ensure that all power is removed from the server before removing or installing a front
Caution -
indicator module. You must disconnect the power cables from the server before performing
these procedures.
Follow these procedures to remove and install the front indicator module (FIM).
"Remove the Front Indicator Module" on page 159
■
"Install the Front Indicator Module " on page 161
■
Related Information
"Disconnect Cables From the Server" on page 56
■
"Remove the Server From the Rack" on page 58
■
"Take Antistatic Measures" on page 59
■
"Open the Server Fan Door" on page 59
■

Remove the Front Indicator Module

The front indicator module should be removed only by authorized Oracle Services
Caution -
personnel.
Prepare the server for service.
1.
a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server to the maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
To remove the top cover from the storage drive cage, do the following [1]:
2.
a. Remove the six Phillips screws from the top of the storage drive cage.
There are three Phillips screws on each side of the storage drive cage.
b. Open the server fan door.
Remove the Front Indicator Module
51.
56.
59.
Servicing FRUs 159
