Servicing the DIMMs (CRU)
The following topics and procedures provide information to assist you when replacing a DIMM
or upgrading DIMMs:
"DIMM and Processor Physical Layout" on page 86
■
"DIMM Population Scenarios" on page 87
■
"DIMM Population Rules" on page 88
■
"Populating DIMMs for Optimal System Performance" on page 88
■
"DIMM Operating Speeds" on page 92
■
"DIMM Rank Classification Labels" on page 92
■
"Inconsistencies Between DIMM Fault Indicators and the BIOS Isolation of Failed
■
DIMMs" on page 92
"Using the Server Fault Remind Button" on page 92
■
"Identify and Remove the Failed DIMM" on page 93
■
"Install a DIMM" on page 95
■
Related Information
"Servicing CRUs That Do Not Require Server Power-Off" on page 63
■
"Servicing FRUs" on page 119
■

DIMM and Processor Physical Layout

The physical layout of the DIMMs and processor(s) is shown in the following figure. When
viewing the server from the front, processor 0 (P0) is on the left. Notice that each processor, P0
and P1, has four memory channels that are labeled, from left to right, Ch C, Ch D, Ch B, and Ch
A.
