Server Internal Cables - Oracle X6-2 Service Manual

FRU Description
NVMe cable Provide signals between the disk backplane and the
Oracle PCIe NVMe switch card.
Related Information
"Customer-Replaceable Units" on page 19
■
"Illustrated Parts Breakdown" on page 17
■
"Servicing FRUs" on page 119
■
"Server Internal Cables" on page 21
■

Server Internal Cables

The following table lists the cables used in the server and directs you to the replacement
instructions.
Cable Name
Internal HBA SAS cable
assembly
Oracle PCIe NVMe switch card
cable assembly
Power cable
FIM cable
Disk backplane data cable
DVD data/power cable
Part Number
7076125
7089783
7064125
7064123
7064127
7064128
Replacement Instructions
"Servicing the NVMe Cables" on page 177
Description
Eight-disk, SAS, combo cable
assembly that connects the
internal host bus adapter (HBA)
card to the disk backplane and
the super capacitor.
Eight-disk backplane, combo
cable assembly that connects the
Oracle PCIe NVMe switch card
to the disk backplane.
Connects the disk backplane
to the motherboard. Provides
power from the motherboard to
the disk backplane.
Ribbon cable that provides a
signal and power connection
between the motherboard to the
Front Module Indicator (FIM)
Ribbon cable that connects
the disk backplane to the
motherboard. Provides a data
connection between the two
components.
Combo cable that connects the
DVD drive to the motherboard.
Provides a data connection
between the two components
and provides power from the
motherboard to the DVD drive.
About the Oracle Server X6-2
About System Components
Removal/Replacement
Instructions
See "Servicing the
Internal HBA SAS Cable
assembly" on page 173
See "Servicing the NVMe
Cables" on page 177
See "Servicing the Power, FIM,
Disk Backplane Data, and DVD
Cables" on page 181
See "Servicing the Power, FIM,
Disk Backplane Data, and DVD
Cables" on page 181
See "Servicing the Power, FIM,
Disk Backplane Data, and DVD
Cables" on page 181
See "Servicing the Power, FIM,
Disk Backplane Data, and DVD
Cables" on page 181
21
