Server Fan Status Indicators

Each fan module has one status indicator (LED). The LEDs are located on the chassis mid-
wall adjacent to and aligned with the fan modules and are visible when the top cover fan door is
open.
Server Fan Status Indicators
TABLE 2
Status Icon
Indicator
Name
Fan Status

Storage Drive Status Indicators

There are three status indicators (LEDs) on each drive.
30 Oracle Server X6-2 Service Manual • June 2016
Icon
TOP
REAR
Color State and Meaning
Amber ■ Off – The fan module is correctly installed and operating within specification.
■ Amber – The fan module is faulty. The front TOP FAN LED and the front and rear
panel Service Required LEDs are also lit if the system detects a fan module fault.
Colors State and Meaning
Amber Indicates that one or more of the internal fan modules
have failed.
■ OFF – Indicates steady state; no service is
required.
■ STEADY ON – Indicates service required.
Amber Indicates that one of the server power supplies has
failed.
■ OFF – Indicates steady state; no service is
required.
■ STEADY ON – Indicates service required;
service the power supply.
Amber Indicates a warning for an over temperature
condition.
■ OFF – Normal operation; no service is required.
■ STEADY ON – The system is experiencing an
overtemperature warning condition.
This is a warning indication, not a fatal
Note -
overtemperature. Failure to correct this might
result in the system overheating and shutting down
unexpectedly.
