Servicing The Power, Fim, Disk Backplane Data, And Dvd Cables - Oracle X6-2 Service Manual

Table of Contents

Advertisement

See
"Install a Fan Module" on page
6.
Return the server to operation.
a.
Install the server top cover.
See
b.
Close the server fan door.
Return the server to the normal rack position.
c.
See
d.
Power on the server.
See
Verify that the Power/OK status indicator is steady on.
Related Information
"Install the NVMe Cables" on page 180
Servicing the Power, FIM, Disk Backplane Data, and DVD
Cables
Caution -
serviced only by authorized Oracle Services personnel.
Caution -
To avoid personal injury or damage to the server, you must disconnect power cords before
servicing the cables.
This section covers the following procedures:
"Remove the Internal HBA SAS Cable Assembly" on page 173
"Install the Internal HBA SAS Cable Assembly" on page 176
Related Information
"Extend the Server to the Maintenance Position" on page 56
"Install the Server Top Cover" on page
"Return the Server to the Normal Rack Position" on page
"Power On the Server" on page
The Power, front indicator module, disk backplane data, and DVD cables should be
The system supplies power to the cables even when the server is powered off.

Servicing the Power, FIM, Disk Backplane Data, and DVD Cables

79.
188.
194.
191.
Servicing FRUs
181
