Figure Legend
1
Power Supply 0 (PS0)
2
Power Supply 1 (PS1)
Pull the power supply out of the chassis [2].
6.
Whenever you remove a power supply, you should replace it with another power
Caution -
supply; otherwise, the server might overheat due to improper airflow.
7. Continue to "Install a Power Supply" on page
Related Information
"Server Back Panel View" on page 16
■
"Power Supply Status Indicators" on page 81
■
"Install a Power Supply" on page 83
■

Install a Power Supply

Always replace a faulty power supply with a power supply of the same type (model).
Caution -
Remove the replacement power supply from its packaging and place it on an
1.
antistatic mat.
2. Align the replacement power supply with the empty power supply slot [1].
3. Slide the power supply into the bay until it is fully seated [2].
83.
