Removing the Power, FIM, Disk Backplane Data, and DVD Cables

"Take Antistatic Measures" on page 59
■
"Remove the Server Top Cover" on page 60
■
Removing the Power, FIM, Disk Backplane Data,
and DVD Cables
Caution -
removed only by authorized Oracle Services personnel.
1. Prepare the server for service.
Power off the server and disconnect the power cords from the power
a.
supplies.
See
b. Extend the server to the maintenance position.
See
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
c.
chassis.
See
d. Remove the server top cover.
See
Remove all of the server fan modules.
2.
See "Remove a Fan Module" on page
3. To remove the disk backplane power cable, perform these steps:
a. To disconnect the disk backplane power cable from the motherboard,
press the release latches on the sides of the cable connector and pull the
connector out. [1].
b. To disconnect the disk backplane power cable from the disk backplane,
press the release latches on the side of the cable connector and pull the
connector out. [2].
182 Oracle Server X6-2 Service Manual • June 2016
The Power, front indicator module, disk backplane data, and DVD cables should be
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
"Remove the Server Top Cover" on page
51.
59.
60.
76.
56.
