PCIe riser and installed cards (2) in slots 3 and 4 (the internal HBA card is installed slot 4 of this riser.) Note:
This riser is different from the risers in slots 1 and 2.
Related Information
"PCIe Slot Characteristics" on page 108
■

Remove a PCIe Riser From PCIe Slot 1 or 2

Either a standard PCIe card (CRU) or the optional PCIe NVMe switch card can be
Note -
installed in the PCIe riser for slot 1. The PCIe NVMe switch card is a field replaceable unit
(FRU) and, therefore, must be removed and replaced only by authorized Oracle Services
personnel. For instructions for servicing the PCIe NVMe switch card, see
PCIe NVMe Switch Card (FRU)" on page
PCIe slot 1 is nonfunctional in single-processor systems.
Note -
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server to the maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
d. Remove the server top cover.
See "Remove the Server Top Cover" on page
2. Select the PCIe riser that you want to remove.
See "PCIe Slot Characteristics" on page
3. If a PCIe card is installed in the riser, disconnect any external cables from the
card.
Remove a PCIe Riser From PCIe Slot 1 or 2
137.
51.
59.
60.
108.
