4
Command Line Interface
Command Mode
Policy Map Configuration
Command Usage
• Use the policy-map command to specify a policy map and enter Policy Map
configuration mode. Then use the class command to enter Policy Map Class
configuration mode. And finally, use the set and police commands to specify
the match criteria, where the:
- set command classifies the service that an IP packet will receive.
- police command defines the maximum throughput, burst rate, and the
action that results from a policy violation.
•
You can configure up to 16 rules per Class Map. You can also include multiple
classes in a Policy Map
Example
This example creates a policy called "rd_policy," uses the class command to specify
the previously defined "rd_class," uses the set command to classify the service that
incoming packets will receive, and then uses the police command to limit the
average bandwidth to 100,000 Kbps, the burst rate to 1522 bytes, and configure the
response to drop any violating packets.
Console(config)#policy-map rd_policy
Console(config-pmap)#class rd_class
Console(config-pmap-c)#set ip dscp 3
Console(config-pmap-c)#police 100000 1522 exceed-action drop
Console(config-pmap-c)#

set

This command services IP traffic by setting a CoS or DSCP, value in a matching
packet (as specified by the match command on page 4-318). Use the no form to
remove the traffic classification.
Syntax
[no] set {cos new-cos | ip dscp new-dscp}
• new-cos - New Class of Service (CoS) value. (Range: 0-7)
• new-dscp - New Differentiated Service Code Point (DSCP) value.
(Range: 0-63)
Default Setting
None
Command Mode
Policy Map Class Configuration
Example
This example creates a policy called "rd_policy," uses the class command to specify
the previously defined "rd_class," uses the set command to classify the service that
incoming packets will receive, and then uses the police command to limit the
4-320
.
