Menu
Association
Port Information
Port Configuration
Trunk Information
Trunk Configuration
Protocol VLAN
Configuration
System Configuration
LLDP
Configuration
Port Configuration
Trunk Configuration
Local Information
Remote Port Information
Remote Trunk Information
Remote Information Details
Device Statistics
Device Statistics Details
Priority
Default Port Priority
Default Trunk Priority
Traffic Classes
Traffic Classes Status
Queue Mode
Queue Scheduling
IP DSCP Priority Status
IP DSCP Priority
Table 3-2 Main Menu (Continued)
Description
Each community VLAN must be associated with a primary VLAN
Shows VLAN port type, and associated primary or secondary
VLANs
Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
Shows VLAN port type, and associated primary or secondary
VLANs
Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
Configures protocol VLANs
Configures protocol VLAN system parameters
Configures global LLDP timing parameters
Configures parameters for individual ports
Configures parameters for trunks
Displays LLDP information about the local device
Displays LLDP information about a remote device connected to
a port on this switch
Displays LLDP information about a remote device connected to
a trunk on this switch
Displays detailed LLDP information about a remote device
connected to this switch
Displays LLDP statistics for all connected remote devices
Displays LLDP statistics for remote devices on a selected port or
trunk
Sets the default priority for each port
Sets the default priority for each trunk
Maps IEEE 802.1p priority tags to output queues
Enables/disables traffic class priorities (not implemented)
Sets queue mode to strict priority or Weighted Round-Robin
Configures Weighted Round Robin queueing
Globally selects DSCP Priority, or disables it.
Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
3
Main Menu
Page
3-211
3-212
3-213
3-212
3-213
3-214
3-215
3-216
3-217
3-217
3-219
3-219
3-222
3-225
3-225
3-226
3-228
3-229
3-230
3-231
3-231
3-232
N/A
3-234
3-234
3-236
3-237
