CLI – This example enables Spanning Tree Protocol, sets the mode to MST, and
then configures the STA and MSTP parameters.
Console(config)#spanning-tree
Console(config)#spanning-tree mode mstp
Console(config)#spanning-tree priority 45056
Console(config)#spanning-tree hello-time 5
Console(config)#spanning-tree max-age 38
Console(config)#spanning-tree forward-time 20
Console(config)#spanning-tree pathcost method long
Console(config)#spanning-tree transmission-limit 4
Console(config)#spanning-tree mst configuration
Console(config-mstp)#revision 1
Console(config-mstp)#name R&D
Console(config-mstp)#max-hops 30
Console(config-mstp)#

Displaying Interface Settings

The STA Port Information and STA Trunk Information pages display the current
status of ports and trunks in the Spanning Tree.
Field Attributes
• Spanning Tree – Shows if STA has been enabled on this interface.
• BPDU Flooding – Shows if BPDUs will be flood to other ports when spanning tree
is disabled globally on the switch or disabled on a specific port.
• STA Status – Displays current state of this port within the Spanning Tree:
• Discarding - Port receives STA configuration messages, but does not forward
packets.
• Learning - Port has transmitted configuration messages for an interval set by
the Forward Delay parameter without receiving contradictory information. Port
address table is cleared, and the port begins learning addresses.
• Forwarding - Port forwards packets, and continues learning addresses.
The rules defining port status are:
- A port on a network segment with no other STA compliant bridging device is
always forwarding.
- If two ports of a switch are connected to the same segment and there is no other
STA device attached to this segment, the port with the smaller ID forwards
packets and the other is discarding.
- All ports are discarding when the switch is booted, then some of them change
state to learning, and then to forwarding.
• Forward Transitions – The number of times this port has transitioned from the
Learning state to the Forwarding state.
• Designated Cost – The cost for a packet to travel from this port to the root in the
current Spanning Tree configuration. The slower the media, the higher the cost.
• Designated Bridge – The bridge priority and MAC address of the device through
which this port must communicate to reach the root of the Spanning Tree.
Spanning Tree Algorithm Configuration
