Summary of Contents for Samsung Ubigate iBG1000

  • Page 2 COPYRIGHT This manual is proprietary to SAMSUNG Electronics Co., Ltd. and is protected by copyright. No information contained herein may be copied, translated, transcribed or duplicated for any commercial purposes or disclosed to the third party in any form without the prior written consent of SAMSUNG Electronics Co., Ltd.

  • Page 3: General User Information

    FCC Requirements This equipment, Ubigate iBG1000, complies with Part 68 of the FCC rules and the requirements adopted by the ATCA. On the bottom of this equipment is a label that contains, among other information, a product identifier in the format US: A3LIS00BiBG1000.
  • Page 4 If requested, this information must be provided to your telephone company. Incidence of Harm If this equipment, Ubigate iBG1000, causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn’t practical, the telephone company will notify the customer as soon as possible.
  • Page 5 Ubigate iBG1000 System Description/Ed.02 Service Center If trouble is experienced with Ubigate iBG1000, please contact your local office of SAMSUNG ELECTRONICS, CO., LTD. for repair or warranty information. If the trouble is causing harm to the telephone network, the telephone company may request that you remove the equipment from the network until the problem is resolved.

  • Page 6: Safety Warning

    Every wire for communication should be larger than 26 AWG. Double pole/neutral fusing. Underwriters Laboratories Ubigate iBG1000 system has been tested to comply with safety standards in the United States and Canada. This system is listed with Underwriters Laboratories. The cUL Mark is separately shown on the label.
  • Page 7 Ubigate iBG1000 System Description/Ed.02 Warning to service personnel: CAUTION: Double pole/neutral fusing Telephone line cord: CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger (e.g., 24 AWG) UL Listed or CSA Certified Telecommunication Line Cord Leakage currents due to ringing voltage - Earthing installation instructions: 1.
  • Page 8 E) Reliable Earthing-Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips).’ © SAMSUNG Electronics Co., Ltd.

  • Page 9: Introduction

    Ubigate iBG1000 System Description INTRODUCTION Purpose Ubigate iBG1000™ System Description describes general information for Ubigate iBG1000 hardware and software. Document Content and Organization This description is composed of three Chapters, one Annex, the Abbreviation, and the Index. CHAPTER 1. Introducing Ubigate iBG1000 Ubigate iBG1000 Overview ...

  • Page 10: Conventions

    Such information may or may not be enclosed in a rectangular box, separating it from the main text, but is always preceded by an icon and/or a bold title. NOTE Indicates additional information as a reference. VIII © SAMSUNG Electronics Co., Ltd.

  • Page 11: Information For Product And Technical Support

    Ubigate iBG1000 System Description/Ed.02 Information for Product and Technical Support For questions regarding the product and technical supports: http://www.samsungnetwork.com Revision History EDITION DATE OF ISSUE REMARKS 03. 2008. First edition 06. 2008. Revised for port name printing changes 08. 2010.
  • Page 12 INTRODUCTION This page is intentionally left blank. © SAMSUNG Electronics Co., Ltd.

  • Page 13: Table Of Contents

    Ubigate iBG1000 Specifications ................. 1-4 Interfaces ........................1-5 Memory ........................1-6 Power Supply ......................1-7 Ventilation ........................1-7 Real-Time Clock ......................1-7 Ubigate iBG1000 Software Features and Licenses ............1-8 Switch/Router Features ....................1-8 Security Features ....................... 1-9 © SAMSUNG Electronics Co., Ltd.
  • Page 14 TABLE OF CONTENTS CHAPTER 2. Hardware Overview Ubigate iBG1000 Chassis ....................2-2 Ubigate iBG1000 Boot Sequence ..................2-3 Ubigate iBG1000 Top Side ....................2-4 Ubigate iBG1000 Rear Side ..................... 2-6 Console Port ....................... 2-6 Auxiliary Port ....................... 2-6 Port Numbering ........................ 2-7 iBG1000 Port Numbering ....................
  • Page 15 Ubigate iBG1000 System Description/Ed.02 ANNEX B. Open Source Announcement ABBREVIATION A ~ G ..........................I H ~ Q ..........................II R ~ W ........................... III INDEX A ~ S ..........................I T ~ W ..........................II XIII © SAMSUNG Electronics Co., Ltd.
  • Page 16 Figure 1.2 Power Supply ..................1-7 Figure 1.3 Ventilation ....................1-7 Figure 2.1 Isometric View ..................2-2 Figure 2.2 Ubigate iBG1000 Top View ..............2-4 Figure 2.3 Ubigate iBG1000 Rear View ..............2-6 Figure 2.4 iBG1000 Port Numbering ................ 2-8 Figure 3.1 iBG-DM Management Network Diagram ..........

  • Page 17: Chapter 1. Introducing Ubigate Ibg1000

    Ubigate iBG1000 Overview Main Features, Functions and Benefits Ubigate iBG1000 router is a Wide Area Network (WAN) router. It is a 1U router that supports multi-protocol routing on WAN/LAN interfaces. Using built-in encryption engine, Ubigate iBG1000 can provide IPSec Virtual Private Network (VPN).

  • Page 18: Branch Office Configuration Example

    In addition, remote management features of Ubigate iBG1000 allow you to graphically configure, monitor or troubleshoot Ubigate iBG1000 as a managed CPE device with ease. With Ubigate iBG1000 on your side, you will boost your revenue while providing a right solution to your customers.

  • Page 19: Figure 1.1 Branch Office Deployment Example

    Ubigate iBG1000 System Description/Ed.02 In Figure 1.1, iBG1000 in Branch office is shown to provide features of a router, a firewall, and a VPN concentrator in a single device. Internet T1/E1 or Metro Ethernet DMZ Server Firewall T1/E1 or Metro Ethernet...

  • Page 20: Product Specifications

    CHAPTER 1. Introducing Ubigate iBG1000 Product Specifications Ubigate iBG1000 Specifications The following table lists specifications for Ubigate iBG1000. Item Specification Router Memory - Typical: 512 MB - Maximum: 1 GB Internal Storage SD Memory: 1 GB Boot Flash 2 MB...

  • Page 21: Interfaces

    Ubigate iBG1000 System Description/Ed.02 Interfaces iBG1000 has four T1/E1 interfaces and two Fast Ethernet ports. E1 WAN Interface Specifications Descriptions Receive line rate 2.048 Mbps ±50 ppm (payload = 1.984 Mbps) Line code HDB3 Framing CRC non-CRC (ITU G.704), and unframed...

  • Page 22: Memory

    1 GB. Internal Flash Memory: Ubigate iBG1000 includes 2 MB of internal flash  memory which is used to boot the router. Ubigate iBG1000 also has 1GB of internal flash memory to store application software and user configuration information.

  • Page 23: Power Supply

    Ubigate iBG1000 System Description/Ed.02 Power Supply Ubigate iBG1000’s AC power adapter provides +12 VDC with an AC input between 100 and 240 VAC. Figure 1.2 Power Supply Ventilation On both sides, there are grids of holes where air comes in and goes out. When installing Ubigate iBG1000, ensure to make room around the system in order not to block air flow.

  • Page 24: Ubigate Ibg1000 Software Features And Licenses

    CHAPTER 1. Introducing Ubigate iBG1000 Ubigate iBG1000 Software Features and Licenses Switch/Router Features The following table lists the switch/router features supported by iBG1000. Category Features and Licenses Layer 2 Protocols - VLAN (802.1q, Port) WAN Protocols - ISDN PRI, HDLC...

  • Page 25: Security Features

    Ubigate iBG1000 System Description/Ed.02 (Continued) Category Features and Licenses Management - Multilevel Administration Access (MLA) - SNMP v1/v2/v3 - CLI, Telnet, SNTP, tftp, DHCP, SSHv2 - Web based GUI, MIBs - Logging & Reporting, Diagnostic - System Image rollback AAA Client...
  • Page 26 CHAPTER 1. Introducing Ubigate iBG1000 (Continued) Category Features and Licenses Management - Reporting - Logging Performance Firewall - Performance: 60 Kpps - Concurrent Sessions: 64 K - Sessions setup rate: 500 sessions/Sec - Performance: 130 Mbps - Maximum Tunnels: 1,500...

  • Page 27: Chapter 2. Hardware Overview

    Hardware Overview Chapter2 describes the hardware overview. Ubigate iBG1000 is enclosed in a 1U enclosure, designed for installing on a desktop or wall-mount. The unit is approximately 10.24-inch wide, 7.48-inch deep and 1.75-inch high. The front side has LED indicators. The rear side has console port, auxiliary port, T1/E1 ports, and Fast Ethernet UTP ports.

  • Page 28: Ubigate Ibg1000 Chassis

    CHAPTER 2. Hardware Overview Ubigate iBG1000 Chassis Ubigate iBG1000 is designed for installing on a desktop or wall-mount. The following figure is an isometric view of the router, with the main chassis without the external enclosure. Figure 2.1 Isometric View...

  • Page 29: Ubigate Ibg1000 Boot Sequence

    Ubigate iBG1000 System Description/Ed.02 Ubigate iBG1000 Boot Sequence All circuitry within Ubigate iBG1000 is reset to its initial state by the reset circuitry on the main board. During normal operation, the reset circuitry monitors an internal power supply of the main board and, after it reaches a normal operating level, generates a reset pulse to the routing processor and all of the other circuitry on the main board.

  • Page 30: Ubigate Ibg1000 Top Side

    CHAPTER 2. Hardware Overview Ubigate iBG1000 Top Side The top side of Ubigate iBG1000 has LEDs in order to indicate the router’s performance and operation status as shown Figure 2.2. Proper LED status is shown as follows. T1/E1 Ethernet Figure 2.2 Ubigate iBG1000 Top View LED Description Indication &...
  • Page 31 Ubigate iBG1000 System Description/Ed.02 (Continued) Indication & Color Description P0~P1 Solid green Ethernet port link is detected. (Ethernet) Blinking green Ethernet port activity is detected. Ethernet port link is not detected. Solid blue Power supply installed and operating normally. (Power)

  • Page 32: Ubigate Ibg1000 Rear Side

    CHAPTER 2. Hardware Overview Ubigate iBG1000 Rear Side Ubigate iBG1000 rear side has four T1/E1 ports, two Fast Ethernet UTP ports, one auxiliary port, and one console port. Console Port Auxiliary Port T1/E1 Ports Fast Ethernet Power Connector UTP Ports Figure 2.3 Ubigate iBG1000 Rear View...

  • Page 33: Port Numbering

    Ubigate iBG1000 System Description/Ed.02 Port Numbering This section describes the port number conventions used by Ubigate routers such as iBG3026, iBG2016, iBG2006, and iBG1000. Ports on a network module are numbered in a format: network module slot- number/interface-number, and ports on a mini-module are numbered in a format: network module slot-number/mini-module slot number/interface- number.

  • Page 34: Ibg1000 Port Numbering

    Therefore, the Fast Ethernet ports are numbered 0/0 and 0/1, starting from right to left. Likewise, the T1/E1 ports are numbered 0/0, 0/1, 0/2, and 0/3, starting from right to left. 0/3 0/2 0/1 Figure 2.4 iBG1000 Port Numbering © SAMSUNG Electronics Co., Ltd.

  • Page 35: Chapter 3. Software Overview

    Network Management Protocol (SNMP), and the Web-based management interface of Ubigate iBG1000. SNMP To allow network management systems to remotely manage Ubigate iBG1000 products, SNMP v1/v2/v3 are supported. The Structure of Management Interface-SMIv1 and SMIv2-as defined by RFC 1155 and 1902 are supported.

  • Page 36: User-Based Security Model (Usm)

    The master-agent will form a TRAP Packet Data Unit (PDU) and forward it to the pre-configured Network Management Station/Trap receiving station. Ubigate iBG1000 product supports more than one trap-host (up to 5) to send traps to. © SAMSUNG Electronics Co., Ltd.

  • Page 37: Command Line Interface (Cli)

    The Command Line Interface forms the link between the end user and the features of the device with a text-based interface. Users can issue commands that need to be executed on Ubigate iBG1000. The CLI provider’s editor support for easy command editing/navigation, command history, and command completion.

  • Page 38: Web Gui (Http Server)

    Web GUI (HTTP Server) The web GUI (iBG-DM) is an additional interface that is supported on Ubigate iBG1000. This allows end users to monitor and configure the device. The GUI is targeted at novice and intermediate users only. The supported browser is Internet Explorer 5.5+.

  • Page 39: Control Plane

    Ubigate iBG1000 System Description/Ed.02 Control Plane The control plane of Ubigate iBG1000 includes routing protocols for L3 routing and spanning tree protocols for L2 packet processing, more specifically: L2 Control Protocol consisting of VLAN management  Unicast Protocols, consisting of Open Shortest Path First (OSPF) and ...

  • Page 40: Multicast Routing Protocols

    Multicast routers use IGMP to learn, for each of their attached physical networks, which groups have members. IGMP should be enabled on both hosts and routers that want to receive multicast traffic. © SAMSUNG Electronics Co., Ltd.

  • Page 41: Wan Protocols

    Reverse Path Multicasting. WAN Protocols Ubigate iBG1000 can use four T1/E1 interfaces for providing WAN connectivity. The protocols such as PPP, Frame Relay, and PPP over Frame Relay (including their multilink variations) are supported in Ubigate iBG1000 to provide link layer connectivity.
  • Page 42 When the bandwidth requirements go beyond a single T1 (and DS3 being expensive or unavailable) multilink PPP can be used to create a bigger bandwidth pipe. © SAMSUNG Electronics Co., Ltd.
  • Page 43 Ubigate iBG1000 System Description/Ed.02 (Continued) WAN Protocols Descriptions ISDN WAN interfaces are connected typically using leased lines such as T1/E1, but there are chances that the T1/E1 links goes down due to various reasons thereby resulting in the loss of wan connectivity.

  • Page 44: Packet Forwarding Plane

    QoS component: This component performs the QoS functions for packets  received from WAN interfaces as well as packets transmitted to WAN interfaces.  Tunneling component: This component performs the GRE and IPIP tunneling functions. 3-10 © SAMSUNG Electronics Co., Ltd.

  • Page 45: Annex A. Cable Specifications

    Ubigate iBG1000 System Description ANNEX A. Cable Specifications Console Port Cable Cable Shape Figure A.1 Console Port Cable Cable Signaling and Pinout Console Port RJ-45 to RJ-45 RJ-45 to DB-9 Terminal Adapter Console (DTE) Rollover Cable (connected to Rollover Cable)

  • Page 46: Auxiliary Port Cable

    ANNEX A. Cable Specifications Auxiliary Port Cable Cable Shape Figure A.2 Auxiliary Port Cable Cable Signaling and Pinout Auxiliary RJ-45 to DB-25 Modem Port (DTE) Modem Adapter Signal RJ-45 Pin DB-9 Pin DB-25 Pin Signal © SAMSUNG Electronics Co., Ltd.

  • Page 47: Ethernet Cable

    Ubigate iBG1000 System Description/Ed.02 Ethernet Cable Cable Shape Cable Length: 6/10 feet  Standard, Straight-Through Wiring (both ends are the same)  10/100/1000Base-T interfaces  Figure A.3 Ethernet LAN Interface Cable Cable Signaling and Pinout RJ45 Pin # Wire Color (T568A)

  • Page 48: T1/E1 Cable

    ANNEX A. Cable Specifications T1/E1 Cable Cable Shape RJ-48C to RJ-48C Cable  Figure A.4 T1/E1 WAN Interface Cable Cable Signaling and Pinout RXRING TXRING RXTIP TXTIP TXRING RXRING TXTIP RXTIP © SAMSUNG Electronics Co., Ltd.
  • Page 49 This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/). To obtain more information on these open source code licenses, please contact nwswmanager@samsung.com Below is the list of components covered under BSD License, libxml2 License and OpenSSL License, which were used to develop software running in the main system.
  • Page 50 Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. © SAMSUNG Electronics Co., Ltd.
  • Page 51 Ubigate iBG1000 System Description/Ed.02 All advertising materials mentioning features or use of this software must display the following acknowledgement: ‘This product includes cryptographic software written by Eric Young(eay@cryptsoft.com)’. The word ‘cryptographic’ can be left out if the rouines from the library being used are not cryptographic related: -).
  • Page 52 ANNEX B. Open Source Announcement This page is intentionally left blank. © SAMSUNG Electronics Co., Ltd.
  • Page 53 Ubigate iBG1000 System Description ABBREVIATION Advanced Encryption Standard CHAP Challenge Handshake Authentication Protocol Command Line Interface Customer Premises Equipment DDR SDRAM Double Data Rate Synchronous Dynamic Random Access Memory Direct Memory Access DVMRP Distance Vector-Multicast Routing Protocol Frame Relay File Transfer Protocol...
  • Page 54 Network Control Protocol OSPF Open Shortest Path First Password Authentication Protocol Packet Data Unit Protocol Independent Multicast PIM-SM Protocol Independent Multicast-Sparse Mode PIM-SSM Protocol Independent Multicast-Specific Source Multicast Point to Point Protocol Quality of Service © SAMSUNG Electronics Co., Ltd.
  • Page 55 Ubigate iBG1000 System Description/Ed.02 Routing Information Protocol Rendezvous Point SNMP Simple Network Management Protocol SODIMM Small Outline Dual In-line Memory Module Transmission Control Protocol TFTP Trivial File Transfer Protocol User Datagram Protocol Unshielded Twisted Pair VLAN Virtual Local Area Network...
  • Page 56 ABBREVIATION This page is intentionally left blank. © SAMSUNG Electronics Co., Ltd.
  • Page 57 Ubigate iBG1000 System Description INDEX Auxiliary Port ....2-7 Interfaces ......1-5 Branch Office MIB Information ....3-1 Configuration Example ..1-2 Multicast Routing Protocols ......3-8 CLI Omnipresent Commands ...... 3-6 Packet Forwarding CLI Privilege Levels ..3-4 Plane ......3-13 Command Line Performance and Interface ......
  • Page 58 Control Model ....3-2 Chassis ......2-2 Ubigate iBG1000 Rear Side ......2-7 Ubigate iBG1000 Routing Engine ....2-1 WAN Protocols ....3-10 Ubigate iBG1000 Web GUI (HTTP Server) . 3-6 Top Side ......2-4 © SAMSUNG Electronics Co., Ltd.
  • Page 59 System Description © 2008~2010 Samsung Electronics Co., Ltd. All rights reserved. Information in this manual is proprietary to SAMSUNG Electronics Co., Ltd. No information contained here may be copied, translated, transcribed or duplicated by any form without the prior written consent of SAMSUNG.
  • Page 60 EQBD-000121 Ed. 02...
