SPECIFICATION CLARIFICATIONS

The Specification Clarifications listed in this section apply to the following documents:
•
®
Pentium II Processor Developer's Manual
•
P6 Family of Processors Hardware Developer's Manual
•
® ®
Intel Celeron Processor Datasheet
•
Intel® 64 and IA-32 Architectures Software Developer's Manual , Volumes 1, 2A, 2B, 3A and 3B.
All Specification Clarifications will be incorporated into a future version of the appropriate Celeron processor
documentation.
C1. PWRGOOD Inactive Pulse Width
In Table 16 of the Intel
®
Celeron
9. When driven inactive or after V
below V IL ,max from Table 8 until all the voltage planes meet the voltage tolerance specifications in Table
6 and BCLK has met the BCLK AC specifications in Table 11 for at least 10 clock cycles. PWRGOOD
must rise glitch-free and monotonically to 2.5 V.
C2. Floating-Point Opcode Clarification
Section 3.2 of the Intel Architecture Software Developer's Manual, Volume 2: Instruction Set Reference,
provides detailed descriptions of each Intel Architecture instruction. For some instructions, the clarification
phrase below needs to either be added to their existing "Comments" section or a "Comments" section needs
to be created with the clarification phrase. The phrase is as follows:
The ( Instruction shown in the center column of the table below) instruction is actually a
combination of two instructions - the FWAIT instruction followed by ( Instruction shown in the
table). If the ( Instruction shown in the table) instruction should fault in some way (e.g., page
fault), the value of EIP that is passed to the fault handler will be equal to the EIP of the first
instruction plus one (i.e., the EIP of the second of the pair of instructions). The FWAIT portion
of the combined instruction will have completed execution and will typically not be, nor need to
be, re-executed after the fault handler is completed.
The following table lists the affected instructions and the location of the clarification phrase:
Instruction Set Reference
Section
FCLEX/FNCLEX-Clear
Exceptions
FINIT/FNINIT-Initialize
Floating-Point Unit
FSAVE/FNSAVE-Store FPU
State
®
INTEL CELERON® PROCESSOR SPECIFICATION UPDATE
Processor Datasheet , footnote 9 should read as follows:
®
, V , and BCLK become stable. PWRGOOD must remain
CC CORE CC L2
Opcode Instruction
9B DB E2 FCLEX
9B DB E3 FINIT
9B DD /6 FSAVE
m94/108byte
Addition
Addition to Page
Add "Comments" 3-177
section with
clarification phrase
Add clarification 3-204
phrase to existing
"Comments"
section
Add clarification 3-237
phrase to existing
97
