1

Port Basic Configuration

Ethernet Port Configuration

Combo Port Configuration

Introduction to Combo port
A Combo port can operate as either an optical port or an electrical port. Inside the device there is only
one forwarding interface. For a Combo port, the electrical port and the corresponding optical port are
TX-SFP multiplexed. You can specify a Combo port to operate as an electrical port or an optical port.
That is, a Combo port cannot operate as both an electrical port and an optical port simultaneously.
When one is enabled, the other is automatically disabled.
Table 1-1 Mapping relations between the ports forming the Combo port
Model
Switch 4210 26-Port
Switch 4210 PWR 26-Port
Switch 4210 18-Port
Switch 4210 PWR 18-Port
Switch 4210 9-Port
Switch 4210 PWR 9-Port
Switch 4210 52-Port does not support Combo port, but it provides two 10/100/1000Base-T
auto-sensing Ethernet ports and two 100/1000Base-X SFP ports on the front panel.
Configuring Combo port state
Follow these steps to configure the state of a Combo port:
Enter system view
Enter Ethernet port view
Enable a specified Combo port
100/1000Base-X SFP port
GigabitEthernet1/0/27
GigabitEthernet1/0/28
GigabitEthernet1/0/19
GigabitEthernet1/0/20
GigabitEthernet1/0/10
To do... Use the command...
system-view
interface interface-type
interface-number
undo shutdown
1-1
10/100/1000Base-T
auto-sensing Ethernet port
GigabitEthernet1/0/25
GigabitEthernet1/0/26
GigabitEthernet1/0/17
GigabitEthernet1/0/18
GigabitEthernet1/0/9
Remarks
—
—
Optional
By default, of the two ports in
a Combo port, the one with a
smaller port ID is enabled.
