To do...
Enter system view
Enter Ethernet port view
Configure the port link type as
Trunk
Allow the specified VLANs to
pass through the current Trunk
port
Configure the default VLAN for
the Trunk port
To convert a Trunk port into a Hybrid port (or vice versa), you need to use the Access port as a
medium. For example, the Trunk port has to be configured as an Access port first and then a Hybrid
port.
The default VLAN IDs of the Trunk ports on the local and peer devices must be the same.
Otherwise, packets cannot be transmitted properly.

Displaying and Maintaining Port-Based VLAN

To do...
Display the hybrid or trunk ports

Port-Based VLAN Configuration Example

Network requirements
As shown in
For data security concerns, the two servers are assigned to VLAN 101 with the descriptive string
being "DMZ", and the PCs are assigned to VLAN 201.
The devices within each VLAN can communicate with each other but that in different VLANs
cannot communicate with each other directly.
Use the command...
system-view
interface interface-type
interface-number
port link-type trunk
port trunk permit vlan
{ vlan-id-list | all }
port trunk pvid vlan vlan-id
Use the command...
display port { hybrid | trunk }
Figure 2-1, Switch A and Switch B each connect to a server and a workstation (Host).
—
—
Required
Required
By default, all Trunk ports only
allow packets of VLAN 1 to
pass.
Optional
VLAN 1 is the default by
default.
Available in any view.
2-5
Remarks
Remarks
