Apply the
existing PoE
profile to the
specified
Ethernet port
Note the following during the configuration:
2) When the apply poe-profile command is used to apply a PoE profile to a port, some PoE features
in the PoE profile can be applied successfully while some cannot. PoE profiles are applied to
Switch 4210 according to the following rules:
When the apply poe-profile command is used to apply a PoE profile to a port, the PoE profile is
applied successfully only if one PoE feature in the PoE profile is applied properly. When the
display current-configuration command is used for query, it is displayed that the PoE profile is
applied properly to the port.
If one or more features in the PoE profile are not applied properly on a port, the switch will prompt
explicitly which PoE features in the PoE profile are not applied properly on which ports.
The display current-configuration command can be used to query which PoE profile is applied to
a port. However, the command cannot be used to query which PoE features in a PoE profiles are
applied successfully.

Displaying PoE Profile Configuration

After the above configuration, execute the display command in any view to see the running status of
the PoE profile and verify the effect of the configuration by checking the displayed information.
Table 2-2 Display the PoE profile configuration
Operation
Display the detailed information
about the PoE profiles created
on the switch

PoE Profile Configuration Example

PoE Profile Application Example

Network requirements
Switch A is an Switch 4210 supporting PoE.
Operation
In system view
Enter
Ethernet
port view
In
Ethernet
Apply the
port view
existing
PoE profile
to the port
display poe-profile { all-profile |
interface interface-type
interface-number | name profile-name }
Command
apply poe-profile
profile-name interface
interface-type
interface-number [ to
interface-type
interface-number ]
interface interface-type
interface-number
apply poe-profile
profile-name
Command
2-2
Description
Use either approach.
Description
Available in any view
