When Switch Acts As Client For Publickey Authentication - 3Com 4210 9-Port Configuration Manual

[SwitchB] local-user client001
[SwitchB-luser-client001] password simple abc
[SwitchB-luser-client001] service-type ssh level 3
[SwitchB-luser-client001] quit
# Configure the authentication type of user client001 as password.
[SwitchB] ssh user client001 authentication-type password
Configure Switch A
# Create a VLAN interface on the switch and assign an IP address, which serves as the SSH client's
address in an SSH connection.
<SwitchA> system-view
[SwitchA] interface vlan-interface 1
[SwitchA-Vlan-interface1] ip address 10.165.87.137 255.255.255.0
[SwitchA-Vlan-interface1] quit
# Establish a connection to the server 10.165.87.136.
[SwitchA] ssh2 10.165.87.136
Username: client001
Trying 10.165.87.136 ...
Press CTRL+K to abort
Connected to 10.165.87.136 ...
The Server is not authenticated. Do you continue to access it?(Y/N):y
Do you want to save the server's public key?(Y/N):n
Enter password:
*****************************************************************************
* Copyright(c) 2004-2009 3Com Corp. and its licensors. All rights reserved.*
* Without the owner's prior written consent,
* no decompiling or reverse-engineering shall be allowed.
*****************************************************************************
<SwitchB>

When Switch Acts as Client for Publickey Authentication

Network requirements
As shown in Figure
(SSH Server) for secure data exchange. The user name is client001 and the SSH server's IP address is
10.165.87.136. Publickey authentication is required.
Network diagram
Figure 1-30 Switch acts as client for publickey authentication
1-30, establish an SSH connection between Switch A (SSH Client) and Switch B
1-38
*
*
