PoE Profile Configuration

Introduction to PoE Profile

On a large-sized network or a network with mobile users, to help network administrators to monitor the
PoE features of the switch, Switch 4210 provide the PoE profile features. A PoE profile is a set of PoE
configurations, including multiple PoE features.
Features of PoE profile:
Various PoE profiles can be created. PoE policy configurations applicable to different user groups
are stored in the corresponding PoE profiles. These PoE profiles can be applied to the ports used
by the corresponding user groups.
When users connect a PD to a PoE-profile-enabled port, the PoE configurations in the PoE profile
will be enabled on the port.
PoE Profile Configuration

Configuring PoE Profile

Table 2-1 Configure PoE profile
Enter system view
Create a PoE profile and enter PoE
profile view
Configure
the relevant
features in
PoE profile
Quit system view
Operation
Enable the PoE feature
on a port
Configure PoE mode for
Ethernet ports
Configure the PoE priority
for Ethernet ports
Configure the maximum
power for Ethernet ports
Command
system-view
poe-profile profilename
poe enable
poe mode { signal |
spare }
poe priority { critical |
high | low }
poe max-power
max-power
quit
2-1
Description
—
Required
If the PoE file is created,
you will enter PoE profile
view directly through the
command.
Required
Disabled by default.
Optional
signal by default.
Optional
low by default.
Optional
15,400 mW by default.
—
