TFTP server configuration
TFTP Configuration: A Switch Operating as a TFTP Client
Basic configurations on a TFTP client
By default a switch can operate as a TFTP client. In this case you can connect the switch to the TFTP
server to perform TFTP-related operations (such as creating/removing a directory) by executing
commands on the switch.
Table 2-2 Basic configurations on a TFTP client
Operation
Download a file from a TFTP
server
Upload a file to a TFTP server
Enter system view
Set the file transmission mode
Specify an ACL rule used by
the specified TFTP client to
access a TFTP server
TFTP Configuration Example
Network requirements
A switch operates as a TFTP client and a PC as the TFTP server. The application named switch.bin is
stored on the PC. Download it (switch.bin) to the switch through TFTP, and use the boot boot-loader
command to specify switch.bin as the application for next startup. Reboot the switch to upload the
configuration file named config.cfg to the work directory on the PC to back up the configuration file.
The TFTP working directory is configured on the TFTP server.
Configure the IP addresses of a VLAN interface on the switch and the PC as 1.1.1.1 and 1.1.1.2
respectively. The port through which the switch connects with the PC belongs to the VLAN.
Network diagram
Figure 2-1 Network diagram for TFTP configurations
TFTP Client
VLAN-Int1
1.1.1.1/8
SwitchA
Item
For details, see the corresponding
manual
Table 2-2 lists the operations that can be performed on a TFTP client.
tftp tftp-server get source-file
[ dest-file ]
tftp tftp-server put source-file
[ dest-file ]
system-view
tftp { ascii | binary }
tftp-server acl acl-number
TFTP Server
2.2.2.2/8
IP network
Configuration task
Command
PC
2-2
Description
—
Description
Optional
Optional
—
Optional
Binary by default
Optional
Not specified by default
