A port working in automatic voice VLAN assignment mode cannot be assigned to the voice VLAN
manually. Therefore, if a VLAN is configured as the voice VLAN and a protocol-based VLAN at the
same time, the protocol-based VLAN function cannot be bound with the port. For information about
protocol-based VLANs, refer to VLAN Configuration in this manual.
For a port operating in automatic voice VLAN assignment mode, its default VLAN cannot be
configured as the voice VLAN; otherwise the system prompts you for unsuccessful configuration.
When the voice VLAN is working normally, if the device restarts, in order to make the established voice
connections work normally, the system does not need to be triggered by the voice traffic to add the port
in automatic voice VLAN assignment mode to the local devices but does so immediately after the restart
or the changes.
Configuring the Voice VLAN to Operate in Manual Voice VLAN Assignment
Mode
Follow these steps to configure a voice VLAN to operate in manual voice VLAN assignment mode:
Enter system view
Set an OUI address that can be identified
by the voice VLAN
Enable the voice VLAN security mode
Set the voice VLAN aging timer
Enable the voice VLAN function globally
To do... Use the command...
system-view
voice vlan mac-address
oui mask oui-mask
[ description text ]
voice vlan security enable
voice vlan aging minutes
voice vlan vlan-id enable
1-9
Remarks
—
Optional
Without this address,
the default OUI
address is used.
Optional
By default, the voice
VLAN security mode is
enabled.
Optional
The default aging timer
is 1,440 minutes.
Required
