In addition to the basic MSTP functions, the 3Com switches 4210 also provide the following functions
for users to manage their switches.
Root bridge hold
Root bridge backup
Root guard
BPDU guard
Loop guard
TC-BPDU attack guard
BPDU dropping

Protocols and Standards

MSTP is documented in:
IEEE 802.1D: spanning tree protocol
IEEE 802.1w: rapid spanning tree protocol
IEEE 802.1s: multiple spanning tree protocol

MSTP Configuration Task List

Before configuring MSTP, you need to know the position of each device in each MSTI: root bridge or
leave node. In each MSTI, one, and only one device acts as the root bridge, while all others as leaf
nodes.
Complete these tasks to configure MSTP:
Configuring
Enabling MSTP
Root Bridge
Configuring an MST Region
Specifying the Current Switch as a Root
Bridge/Secondary Root Bridge
Configuring the Bridge Priority of the
Current Switch
Configuring How a Port Recognizes and
Sends MSTP Packets
Configuring the MSTP Operation Mode
Configuring the Maximum Hop Count of an
MST Region
Configuring the Network Diameter of the
Switched Network
Configuring the MSTP Time-related
Parameters
Task
1-15
Remarks
Required
To prevent network topology jitter
caused by other related configurations,
you are recommended to enable MSTP
after other related configurations are
performed.
Required
Required
Optional
The priority of a switch cannot be
changed after the switch is specified as
the root bridge or a secondary root
bridge.
Optional
Optional
Optional
Optional
The default value is recommended.
Optional
The default values are recommended.
