Log Output To The Console; Configuration Example - 3Com 4210 9-Port Configuration Manual

Through combined configuration of the device name (facility), information severity level threshold
(severity), module name (filter) and the file "syslog.conf", you can sort information precisely for filtering.

Log Output to the Console

Network requirements
The switch sends the following information to the console: the log information of the two modules ARP
and IP, with severity higher than "informational".
Network diagram
Figure 1-3 Network diagram for log output to the console
Configuration procedure
# Enable the information center.
<Switch> system-view
[Switch] info-center enable
# Disable the function of outputting information to the console channels.
[Switch] undo info-center source default channel console
# Enable log information output to the console. Permit ARP and IP modules to output log information
with severity level higher than informational to the console.
[Switch] info-center console channel console
[Switch] info-center source arp channel console log level informational debug state off trap
state off
[Switch] info-center source ip channel console log level informational debug state off trap
state off
# Enable terminal display.
<Switch> terminal monitor
<Switch> terminal logging

Configuration Example

Network requirements
The switch is in the time zone of GMT+ 08:00:00.
The time stamp format of output log information is date.
UTC time zone will be added to the output information of the information center.
1-18
