If they are consistent, the packet passes the check and the switch learns the ARP entry.
If they are not consistent, the ARP packet is considered invalid and the corresponding ARP entry is
not learned.

Enabling ARP Source MAC Address Consistency Check

To do...
Enter system view
Enable ARP source MAC
address consistency check

ARP Attack Defense Configuration Example I

Network Requirements

Host A and Host B are connected to Gateway through an access switch (Switch). The IP and MAC
addresses of Gateway are 192.168.100.1/24 and 000D-88F8-528C. To prevent gateway spoofing
attacks from Host A and Host B, configure ARP packet filtering based on the gateway's IP and MAC
addresses on Switch.

Network Diagram

Figure 1-2 Network diagram for ARP attack defense I
Gateway
Eth1/0/2
Switch
Host A

Configuration Procedures

# Enter system view.
<Switch> system-view
# Configure ARP packet filtering based on the gateway's IP and MAC addresses on Ethernet 1/0/1.
[Switch] interface Ethernet 1/0/1
[Switch-Ethernet1/0/1] arp filter binding 192.168.100.1 000d-88f8-528c
[Switch-Ethernet1/0/1] quit
Use the command...
system-view
arp anti-attack valid-check
enable
Vlan-int 1
192.168.100.1/24
MAC:000D-88F8-528C
Eth1/0/1
Eth1/0/3
Host B
—
Required
Disabled by default.
5
Remarks
