DHCP Server Configuration Examples

DHCP Server Configuration Example

Network requirements
The DHCP server (Switch A) assigns IP address to clients in subnet 10.1.1.0/24, which is
subnetted into 10.1.1.0/25 and 10.1.1.128/25.
The IP addresses of VLAN-interface 1 and VLAN-interface 2 on Switch A are 10.1.1.1/25 and
10.1.1.129/25 respectively.
In the address pool 10.1.1.0/25, the address lease duration is ten days and twelve hours, domain
name suffix aabbcc.com, DNS server address 10.1.1.2, gateway 10.1.1.126, and WINS server
10.1.1.4.
In the address pool 10.1.1.128/25, the address lease duration is five days, domain name suffix
aabbcc.com, DNS server address 10.1.1.2, and gateway address 10.1.1.254, and there is no
WINS server address.
