Clear IPv6 neighbor information
Clear the statistics of IPv6 packets
Clear the statistics of all IPv6 TCP
packets
Clear the statistics of all IPv6 UDP
packets
The display dns domain and display dns server commands are the same as those of IPv4 DNS. For
details about the commands, refer to DNS.

IPv6 Configuration Example

IPv6 Unicast Address Configuration

Network requirements
Two switches are directly connected through two Ethernet ports. The Ethernet ports belong to VLAN 1.
IPv6 addresses are configured for the interface Vlan-interface1 on each switch to verify the connectivity
between the two switches. The global unicast address of Switch A is 3001::1/64, and the global unicast
address of Switch B is 3001::2/64.
Network diagram
Figure 1-5 Network diagram for IPv6 address configuration
Configuration procedure
1) Configure Switch A.
# Configure an automatically generated link-local address for the interface Vlan-interface1.
<SwitchA> system-view
[SwitchA] interface Vlan-interface 1
[SwitchA-Vlan-interface1] ipv6 address auto link-local
# Configure a global unicast address for the interface Vlan-interface1.
[SwitchA-Vlan-interface1] ipv6 address 3001::1/64
2) Configure Switch B.
To do... Use the command...
reset ipv6 neighbors [ all | dynamic |
interface interface-type
interface-number | static ]
reset ipv6 statistics
reset tcp ipv6 statistics
reset udp ipv6 statistics
1-16
Remarks
