Logging Out A Web User; Configuration Example - 3Com 4210 9-Port Configuration Manual

To do...
Enter system view
Create a basic ACL or enter
basic ACL view
Define rules for the ACL
Quit to system view
Apply the ACL to control
Web users

Logging Out a Web User

The administrator can log out a Web user using the related command.
Follow the step below to log out a Web user:
To do...
Log out a Web user

Configuration Example

Network requirements
Only the Web users sourced from the IP address of 10.110.100.52 are permitted to access the switch.
Network diagram
Figure 8-3 Network diagram for controlling Web users using ACLs
10.110.100.46
Host A
IP network
Host B
10.110.100.52
Configuration procedure
# Define a basic ACL.
<Sysname> system-view
[Sysname] acl number 2030
[Sysname-acl-basic-2030] rule 1 permit source 10.110.100.52 0
Use the command...
system-view
acl number acl-number
[ match-order { config | auto } ]
rule [ rule-id ] { deny | permit }
[ rule-string ]
quit
ip http acl acl-number
Use the command...
free web-users { all | user-id user-id |
user-name user-name }
Switch
8-6
Remarks
—
As for the acl number
command, the config keyword
is specified by default.
Required
—
Optional
By default, no ACL is applied
for Web users.
Remarks
Required
Available in user view
