Configuring a Port in Access Mode

Beginning in Privileged EXEC mode, use the following commands to
configure an untagged layer 2 VLAN interface and assign the interface to a
VLAN. When a port is in access mode, it can only be a member of one
untagged VLAN. When you configure the interface as a VLAN member, the
interface is automatically removed from its previous VLAN membership. You
can configure each interface separately, or you can configure a range of
interfaces with the same settings.
Command
configure
interface
interface
switchport mode access
switchport access vlan
vlan-id
CTRL + Z
show interfaces
interface
switchport
Purpose
Enter global configuration mode.
Enter interface configuration mode for the specified
interface
interface. The
and number, for example tengigabitethernet 1/0/3.
You can also specify a range of interfaces with the interface
range command, for example, interface range
tengigabitethernet 1/0/8-12 configures interfaces 8, 9, 10,
11, and 12.
Configure the interface as an untagged layer 2 VLAN
interface.
Configure the interface as a member of the specified
VLAN.
vlan-id
— A valid VLAN ID of the VLAN to which the port
is configured. (Range: 1–4093)
Exit to Privileged EXEC mode.
Display information about the VLAN settings configured
for the specified interface.
variable includes the interface type
Configuring VLANs
577
