Table 22-10 shows the port assignments on the switches.
Table 22-10. Switch Port Connections
Port/LAG
Switch 1
1
2–15
16–20
LAG1 (ports 21–24)
Switch 2
1
2–10
11–30
LAG1 (ports 35–39)
LAG2 (ports 40–44)
Function
Connects to Switch 2
Host ports for Payroll
Host ports for Marketing
Connects to Payroll server
Connects to Switch 1
Host ports for Marketing
Host ports for Engineering
Connects to file server
Uplink to router.
