Basic Failover

In this example, the stack has four members that are connected through a
daisy-chain, as Figure 9-11 shows.
Figure 9-11. Basic Stack Failover
When all four units are up and running, the show switch CLI command gives
the following output:
console#show switch
SW Management
Status
--- ---------
1 Stack Member
2 Stack Member
3 Mgmt Switch
4 Stack Member
166
Managing a Switch Stack
Standby Preconfig
Status Model ID
------- --------
PC8024
PC8024
PC8024
PC8024F
Plugged- Switch
in Model Status
ID
--------- -------
---
PC8024 OK
PC8024 OK
PC8024 OK
PC8024F OK
Code
Version
--------
9.19.0.2
9.19.0.2
9.19.0.2
9.19.0.2
