Operator configuration of PFC is used only when the port is configured in a
manual role. When interoperating with other equipment in a manual role,
the peer equipment must be configured with identical PFC priorities and
VLAN assignments. Interfaces not enabled for PFC ignore received PFC
frames. Ports configured in auto-upstream or auto-downstream roles receive
their PFC configuration from the configuration source and ignore any
manually configured information.
NOTE:
This feature is configurable on physical full duplex interfaces only. To
enable PFC on a LAG interface, the member interfaces must have the same
configuration.
When PFC is disabled, the interface defaults to the IEEE 802.3 flow control
setting for the interface. PFC is disabled by default.
If you enable priority-based flow control for a particular priority value on an
interface, ensure that Voice VLAN tagging is enabled on the interface so that
the 802.1p priority values are carried through the network (see "Voice VLAN"
on page 545). Additionally, make sure that 802.1p priority values are mapped
to CoS values (see "Configuring Class-of-Service" on page 1133).
PFC can be configured using the web interface and the command line
interface.

Configuring PFC Using the Web Interface

This section provides information about the OpenManage Switch
Administrator pages to use to view and configure PFC on PowerConnect
8000-series and 8100-series switches. For details about the fields on a page,
click at the top of the page.
NOTE:
FIP snooping can be enabled, configured, and monitored only by using
the CLI.
PFC Configuration Page
Use the PFC Configuration page to enable priority flow control on one or
more interfaces and to configure which priorities are subject to being paused
to prevent data loss.
To display the PFC Configuration page, click Switching → PFC → PFC
Configuration in the navigation menu.
