Auto Configuration Example

A network administrator is deploying three PowerConnect switches and wants
to quickly and automatically install the latest image and a common
configuration file that configures basic settings such as VLAN creation and
membership, RADIUS server settings, and 802.1X information. The
configuration file also contains the command boot host autosave so that the
downloaded configuration is automatically saved to the startup config.

Enabling DHCP Auto Configuration and Auto Image Download

If no configuration file is found during the boot process, the Auto
Configuration feature uses the DHCP Auto Configuration process to
download the configuration file to the switch. This example describes the
procedures to complete the configuration.
To use DHCP auto configuration:
1 Create a default config file for the switches named host.cfg. For
information about creating configuration files, see Managing Images and
Files.
2 Upload the host.cfg file to the TFTP server.
3 Upload the image file to the TFTP server.
4 Configure an address pool on the DHCP server that contains the following
information:
The IP address (
a
the interface
The IP address of a default gateway (option 3)
b
DNS server address (option 6)
c
Name of config file for each host
d
Identification of the TFTP server by hostname (DHCP option 66 or
e
sname field in the DHCP header) or IP address (DHCP option
the
150 or the
Name of the text file (option 125, the V-I vendor-specific Information
f
option) that contains the path to the image file.
344
Auto Image and Configuration Update
yiaddr ) and subnet mask (option 1) to be assigned to
siaddr field in the DHCP header)
