Interoperability with IEEE DCBx

To be interoperable with legacy industry implementations of the DCBx
protocol, The PowerConnect 8024/8024F switches use a hybrid model to
support both the IEEE version of DCBx (IEEE 802.1Qaz) and legacy DCBx
versions.
The PowerConnect 8024/8024F switch automatically detects whether a peer
is operating with either of the two CEE DCBx versions or the IEEE standard
DCBx version (the default mode). You can also configure DCBx to manually
select one of the legacy versions or IEEE standard mode. In auto-detect
mode, the switch starts operating in IEEE DCBx mode on a port, and if it
detects a legacy DCBx device based on the OUI of the organization TLV, then
the switch changes its DCBx mode on that port to support the version
detected. There is no timeout mechanism to move back to IEEE mode. Once
the DCBx peer times out, multiple peers are detected, the link is reset (link
down/up) or as commanded by the operator, DCBx resets its operational
mode to IEEE.
The interaction between the DCBx component and other components
remains the same irrespective of the operational mode it is executing. For
instance, the DCBx component interacts with PFC to get needed
information to pack the TLVs to be sent out on the interface. Based on the
operational control mode of the port, DCBx packs it in the proper frame
format.

DCBx and Port Roles

The behavior of each port is dependent on its operational mode and that of
other ports in the stack. The port mode is a DCBx configuration item that is
passed to the DCBx clients to control the processing of their configuration
information. There are four port roles:
1 Manual
2 Auto-Upstream
3 Auto-Downstream
4 Configuration Source
Ports operating in the manual role do not have their configuration affected by
peer devices or by internal propagation of configuration. These ports have
their operational mode, traffic classes, and bandwidth information specified
