Configuring Link Aggregation

This chapter describes how to create and configure link aggregation groups
(LAGs), which are also known as port channels.
The topics covered in this chapter include:
•

Link Aggregation Overview

• Default Link Aggregation Values
• Configuring Link Aggregation (Web)
• Configuring Link Aggregation (CLI)
• Link Aggregation Configuration Examples
Link Aggregation Overview
Link Aggregation allows one or more full-duplex (FDX) Ethernet links of the
same speed to be aggregated together to form a LAG. This allows the switch
to treat the LAG as if it is a single link.
The PowerConnect 8000-series and 8100-series switches support industry-
standard LAGs that adhere to the IEEE 802.3ad specification. The maximum
number of LAGs that may be configured is limited to the maximum number
of ports possible in the switch stack or stand-alone switch divided by two.
This allows for a flexible configuration of LAGs where LAGs may have up to
eight ports or as few as two ports. You can configure LAGs until all ports in
the system are assigned to a LAG.
Assignment of interfaces to dynamic LAGs is based on a maximum of 144
interfaces assigned to dynamic LAGs, a maximum of 72 dynamic LAGs and a
maximum of 8 interfaces per dynamic LAG. For example, 72 LAGs may be
assigned 2 interfaces each, or 18 LAGs may be assigned 8 interfaces each.
Each PowerConnect 8000-series and 8100-series switches supports a
maximum of 7 static or dynamic LAGs. Each LAG can consist of up to eight
10 Gbps ports. When eight 10 Gbps ports are configured as a LAG, the
maximum bandwidth for the single, logical interface is 80 Gbps.
