Configuring The Static Area Range Cost - Dell PowerConnect 8024 User Configuration Manual

console(config-if-tunnel0)#tunnel destination
20.20.20.1
console(config-if-tunnel0)#ipv6 ospf
console(config-if-tunnel0)#ipv6 ospf network
point-to-point
console(config-if-tunnel0)#exit
8 Configure the loopback interface. The switch uses the loopback IP address
as the OSPF and OSPFv3 router ID.
console(config)#interface loopback 0
console(config-if-loopback0)#ip address 2.2.2.2
255.255.255.0
console(config-if-loopback0)#exit
console(config)#exit

Configuring the Static Area Range Cost

Figure 35-39 shows a topology for the configuration that follows.
Figure 35-39. Static Area Range Cost Example Topology
1 Configure R0.
terminal length 0
config
1008
Configuring OSPF and OSPFv3
R3
VLAN 103
ABR
R0
VLAN 101
VLAN 104
R1
Area 1
Area 0
VLAN 102
R2
