VRRP Configuration Example
This section contains the following VRRP examples:
•
VRRP with Load Sharing
•
VRRP with Route and Interface Tracking
VRRP with Load Sharing
In Figure 37-9, two L3 PowerConnect switches are performing the routing for
network clients. Router A is the default gateway for some clients, and Router
B is the default gateway for other clients.
Figure 37-9. VRRP with Load Sharing Network Diagram
Default Gateway
192.168.10.1
1050
Configuring VRRP
VRID 10: 192.168.10.1
VRID 20: 192.168.10.2
Router A
VLAN 10
192.168.10.1
`
`
Default Gateway
192.168.10.1
External Network
VLAN 10
192.168.10.2
L2 Switch
Default Gateway
192.168.10.2
Router B
`
`
Default Gateway
192.168.10.2
