System LEDs

The system LEDs, located on the back panel, provide information about the
power supplies, thermal conditions, and diagnostics.
Table 3-2 shows the System LED definitions for the 8000-series switches.
Table 3-2. System LED Definitions—PowerConnect 8000-Series Switches
LED Color
DIAG Flashing Green
Green
Red
PWR Green
Red
FAN Green
Red
Temp Amber
Table 3-3 shows the System LED definitions for the 8100-series switches.
96
Hardware Overview
Definition
A diagnostics test is in progress.
The diagnostics test was successfully completed.
The diagnostics test failed.
Power Supply is operating correctly.
Power Supply has failed.
Fans are operating correctly.
One or more fans have failed.
System temperature has exceeded threshold limit.
