FIGURE 1-1
Number
1
2
3
4
5
6
RCI Port
When connecting a peripheral device with an RCI connector to the system, the RCI
port is used for interlocking with a power supply and error monitoring.
Note – To use the RCI function, the server or I/O devices must have a RCI port.
1-4 SPARC Enterprise Mx000 Servers XSCF User's Guide • August 2009
Outline Drawing of the Rear Panel (In the Entry-level Server)
Description
RCI port
USB port
READY LED
CHECK LED
Serial port
Link Speed LED
Number Description
7 ACT LED
8 LAN 1 port
(XSCF-LAN#1 port)
9 LAN 0 port
(XSCF-LAN#0 port)
10 UPC 1 port
11 UPC 0 port
