Sun SPARC
Enterprise
®
M4000/M5000/M8000/M9000
Servers Capacity on Demand
(COD) User's Guide
Sun Microsystems, Inc.
www.sun.com
Part No. 819-7417-11
September 2007, Revision A
Submit comments about this document at: http://www.sun.com/hwdocs/feedback

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPARC Enterprise M4000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems SPARC Enterprise M4000

Summary of Contents for Sun Microsystems SPARC Enterprise M4000

  • Page 1 Sun SPARC Enterprise ® M4000/M5000/M8000/M9000 Servers Capacity on Demand (COD) User’s Guide Sun Microsystems, Inc. www.sun.com Part No. 819-7417-11 September 2007, Revision A Submit comments about this document at: http://www.sun.com/hwdocs/feedback...
  • Page 2 Fujitsu Limited or Sun Microsystems, Inc., or any affiliate of either of them.
  • Page 3 Aucune partie de ce produit, de ces technologies ou de ce document ne peut être reproduite sous quelque forme que ce soit, par quelque moyen que ce soit, sans l’autorisation écrite préalable de Fujitsu Limited et de Sun Microsystems, Inc., et de leurs éventuels bailleurs de licence.

  • Page 5: Table Of Contents

    Contents Preface vii Capacity on Demand (COD) Administration 1 About Capacity on Demand 1 COD Boards 2 COD License Purchase 3 License Installation 3 License Allocation 4 Headroom Management 5 License Violations 5 Instructions for Purchasing a COD License 6 ▼...
  • Page 6 ▼ To Display COD License Status 13 ▼ To Display Usage Statistics for COD Resources 14 Related Information 15 Index 17 Sun SPARC Enterprise Mx000 Servers Capacity on Demand (COD) User’s Guide • September 2007...

  • Page 7: Preface

    Preface This manual describes how to manage system resources with the Capacity on ® Demand (COD) feature of the Sun SPARC Enterprise M4000/M5000/M8000/M9000 server, including special instructions for ordering and installing your license. Using UNIX Commands ® This document might not contain information about basic UNIX commands and procedures such as shutting down the system, booting the system, and configuring devices.
  • Page 8 Shell Prompts Shell Prompt C shell machine-name% C shell superuser machine-name# Bourne shell and Korn shell Bourne shell and Korn shell superuser Typographic Conventions Typeface Meaning Examples The names of commands, files, Edit your.login file. AaBbCc123 and directories; on-screen Use ls -a to list all files. computer output % You have mail.
  • Page 9 Application Title Format Location Service Sun SPARC Enterprise M4000/M5000 Servers Service HTML Online Manual Service Sun SPARC Enterprise M8000/M9000 Servers Service HTML Online Manual Software Sun SPARC Enterprise M4000/M5000/M8000/M9000 HTML Online Administration Servers Administration Guide Software Sun SPARC Enterprise M4000/M5000/M8000/M9000...
  • Page 10 Sun Welcomes Your Comments Sun is interested in improving its documentation and welcomes your comments and suggestions. You can submit your comments by going to: http://www.sun.com/hwdocs/feedback Please include the title and part number of your document with your feedback: ® Sun SPARC Enterprise M4000/M5000/M8000/M9000 Servers Capacity on Demand (COD) User’s Guide, part number 819-7417-11...

  • Page 11: Capacity On Demand (Cod) Administration

    Capacity on Demand (COD) Administration This guide describes how to manage system resources with the Capacity on Demand ® (COD) feature of the Sun SPARC Enterprise M4000/M5000/M8000/M9000 server. It includes special instructions for ordering and installing your license, and special instructions for trading your COD license.

  • Page 12: Cod Boards

    High-end servers support any combination of COD boards and system boards. For Sun SPARC Enterprise M4000/M5000 (midrange) servers, COD boards can be ordered only at original purchase. Midrange systems can be configured with COD boards or system boards, but not both.

  • Page 13: Cod License Purchase

    COD License Purchase The purchase of a COD RTU license from the Sun License Center entitles you to receive a license key, which enables the appropriate number of COD processors. A license key can grant access to multiple RTUs. A COD license is assigned to a specific server, one license per processor (CPU). All the licenses assigned to a server are handled as a floating pool of licenses for all the COD processors installed on that server.

  • Page 14: License Allocation

    License Allocation The software allocates COD licenses automatically on a first-come, first-served basis. However, you can reserve licenses if you want to make sure a specific number of COD licenses are allocated to a particular domain. Licenses are allocated to COD resources either when a domain with a COD board is powered on or when a new COD board is installed and powered on.

  • Page 15: Headroom Management

    Headroom Management Headroom is the capability to use up to four COD processors per server before actually purchasing a license. Headroom allows you to activate a COD board under these conditions: As a hot spare to replace a failed system board ■...

  • Page 16: Instructions For Purchasing A Cod License

    Instructions for Purchasing a COD License ▼ To Obtain a COD RTU License and License Key 1. Contact your Sun sales representative or authorized Sun reseller to purchase a COD RTU license for each COD CPU to be enabled. Sun will send you a COD RTU License Certificate for each CPU license that you purchase.

  • Page 17: Xscf Shell Procedures For Using Cod

    XSCF Shell Procedures for Using COD This section describes these tasks: To Install a COD License ■ To Delete a COD License ■ To Trade a COD License ■ To Reserve Licenses for Allocation ■ To Increase or Decrease Headroom ■...

  • Page 18: To Delete A Cod License

    To Delete a COD License ▼ Before deleting a license, the COD software determines whether sufficient licenses are available from the pool of installed licenses plus headroom. If all licenses are in use and no headroom is available, the operation will fail. You can force the operation by using the -f option in Step 3, but doing so will overcommit any license...

  • Page 19: To Reserve Licenses For Allocation

    4. Install the replacement license in the new server, as described in “To Install a COD License” on page ▼ To Reserve Licenses for Allocation You need to reserve licenses only if you want to make sure a specific number of COD licenses are allocated to a particular domain.

  • Page 20: To Increase Or Decrease Headroom

    b. Enter the number of licenses reserved for each domain. The currently reserved number appear in parentheses. Do not exceed the number of available licenses. To leave a reservation unchanged, press Return. 3. Verify the allocation with the showcod command. To Increase or Decrease Headroom ▼...

  • Page 21: To Disable Headroom

    Note – When headroom is in use, the XSCF console displays periodic warning messages requesting installation of new licenses. The warning messages continue to be displayed until new license keys are installed, or headroom is no longer in use. Headroom warning messages are similar to: codd[627]: COD PROC WARNING: Headroom Active: License key(s) must be installed ▼...

  • Page 22: To Display Cod Information

    To Display COD Information ▼ 1. Log in to the XSCF console with platadm, platop, domainadm, or domainop privileges, or domainmgr privileges for a specific domain. 2. Type the showcod command. The output displays the server’s Chassis HostID, number of licenses (PROC RTUs installed), headroom quantity, and number of licenses reserved for each domain.
  • Page 23 To Display COD License Status ▼ 1. Log in to the XSCF console with platadm or platop privileges. 2. Type the showcodlicense command. The output displays the resource description, license version number, expiration date, number of licenses, and license status. For example: XSCF>...
  • Page 24 To Display Usage Statistics for COD Resources ▼ 1. Log in to the XSCF console with platadm or platop privileges, or domainadm, domainop, or domainmgr privileges for a specific domain. 2. Type the showcodusage command. The output displays a summary of license usage by resource type and for each domain.
  • Page 25 Related Information For additional information, see: Resource Information man pages or SPARC Enterprise setcod(8), showboards(8), showcodusage(8), M4000/M5000/M8000/M9000 Servers XSCF Reference showcodlicense(8), showcod (8), Manual addcodlicense(8), deletecodlicense(8) Service Manual for your server COD boards Dynamic Reconfiguration User’s Guide COD boards Capacity on Demand (COD) Administration...
  • Page 26 Sun SPARC Enterprise Mx000 Servers Capacity on Demand (COD) User’s Guide • September 2007...
  • Page 27 Index showcodlicense command, 7, 8, 13 showcodusage command, 14 addcodlicense command, 5, 7 Capacity on Demand, see COD Chassis HostID, 3, 6 boards, 2 headroom, 5, 7, 8, 10, 11, 12 license database, 3 license violation, 5 commands addcodlicense, 5, 7 deletecodlicense, 5, 8 setcod, 4, 5, 9, 10, 11 showcod, 6, 10, 12...
  • Page 28 Sun SPARC Enterprise Mx000 Servers Capacity on Demand (COD) User’s Guide • September 2007...
